Specification

Mode of operation : Maintained

Input voltage : 85 - 245 Vac / 50 Hz

Lamp : mid-power / high-lumen LEDs – brightness complying with EIT 2004-54

Color temperature : 6500 K

Signage : Light-diffusing shinkolite acrylic sandwiched between two white Shinkolite acrylic sheets

Battery : Nicket metal hydride (NiMH) 3 x 1.2 V 2100 mAh

Backup time : 3 hrs

Battery charging method : Automatic solid-state system with constant voltage and current limit

Battery cut-off voltage : 1.0 V / cell Maximum

Charging current : 230 mA

Charging time : 10 -15 hrs

Manual test : For LX-N series : performed bypushing Test button For LX-R series : either pushing Test button or using remote control

Remote* : Remote control for manual test (for LX-R series only)

Standards : TIS 1955-2551 , ISO 9001

Casing : For ceiling-mounted, wall-mounted, and ceiling-hung types: 1.1-mm-thick extruded aluminum coated with powder paint For ceiling recessed type: 0.8-mm-thick streel sheet coated eith powder paint
